3117-PB Double-Ridged Waveguide Horn with Pre-Amplifier
The Model 3117-PB is a specially calibrated version of the Model 3117 Double-Ridged Waveguide Antenna with an integrated pre-amplifier, designed to account for antenna-pre-amplifier mismatches, but not intended for RSE testing of intentional radiators.
Add to FavoritesRemove from Favorites
Add to Favorites
Amplified Accuracy in Every Measurement
The Model 3117-PB is a specialized version of the Model 3117 Double-Ridged Waveguide Antenna, equipped with a pre-amplifier package and calibrated as a single unit. This calibration accounts for any mismatches between the antenna and pre-amplifier, which is reflected in the provided antenna factor (AF). Please note that the 3117-PB is not intended for radiated spurious emission (RSE) testing of intentional radiators.
Key Features:
- Frequency Range: 1 GHz to 18 GHz.
- Maintains Single Lobe Radiation, Allowing Accurate Measurement of Gains and Emissions
- Fitted with a Pre-Amplifier for Increased Sensitivity
- Extremely Low Antenna Factor
- Flexible Mounting
